ZUMBACH - JUROCA Z 14 is a Rotary transfer machine of high precision, engineered for excellent accuracy and reliability. Capacities: 14 working positions, 6 CNC-controlled and 8 mechanical; 1 loading/unloading station; table travel 20 mm; workspace 40 mm; screw diameters 75/35/42 mm; spindle speeds 3000–18000 t/min; production 35 pcs/min. Technical data: 3x400 V 50 Hz supply; machine weight ~3500 kg; footprint 2000×2000×2400 mm; control cabinet 1200×1200×2100 mm. Equipment: integrated control cabinet (dimensions given). Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical.
| Number of working positions | 14 |
| CNC Controlled | 6 |
| mechanical | 8 |
| Number of loading/unloading items | 1 |
| Way of the table | 20 mm |
| Workspace | 40 mm |
| Screw diameter | 75/35/42 mm |
| Spindle speeds: | |
| from | 3000 t/min |
| up to | 18000 t/min |
| Production capacity | 35 pce/min |
| Voltage 50 Hz 3x | 400 Volt |
| Machine's weight about | 3500 kg |
| Overall dimensions machine: | |
| Length | 2000 mm |
| Width | 2000 mm |
| Height | 2400 mm |
| Dimensions of the control: | |
| Length | 1200 mm |
| Width | 1200 mm |
| Height | 2100 mm |
