ZUMBACH MSF 14 is a Rotary transfer machine delivering precision, high accuracy and reliable performance. Capacity: 14 working positions; table way 20 mm; longitudinal slide way up to 40 mm; transversal slide way up to 40 mm; spindle speeds from 3000 t/min up to 18000 t/min; production capacity 35 pce/min. Technical specifications: Voltage 50 Hz 3x 380 Volt; machine's weight about 3500 kg; overall dimensions L1800 x W1600 x H2100 mm. Engineered to achieve tight tolerances; typical applications include automotive, watchmaking, machine tools, aerospace and medical sectors.

Technical specifications are subject to change without notice
