| Min. diameter threaded | 2 mm |
| Max. diameter threaded | 50 mm |
| Min. pitch | 0.35 mm |
| Max. pitch | 3 mm |
| Max. infeed length | 85 mm |
| Min. roll die diameter | 120 mm |
| Roll die width | 90 mm |
| Roller pressure infinitely adjustable | 12 to |
| Roll axis swivel for thru-feed | 8 ° |
| Max. working stroke | 125 mm |
| Roll speeds: | |
| stepless | |
| from | 30 t/min |
| up to | 150 t/min |
| Voltage 50 Hz 3x | 400 Volt |
| Motor power | 7.5 kW |
| Connection power | 8 kW |
| Machine's weight about | 2000 kg |
| Overall dimensions machine: | |
| Length | 1440 mm |
| Width | 1260 mm |
| Height | 1805 mm |
