ISELI AS 2 is a Sawblade sharpening machine designed for precision, high accuracy and reliable operation. Capacities: blade Ø 250–1200 mm; tooth spacing 15–100 mm/tooth; tooth height 40 mm; bore 22–210 mm; clamping angle 0–30°; grinding angle 0–15°. Specs: grinding wheel Ø 200/250 mm, max width 16 mm, wheel bore 25 mm; feeds 4 steps; coolant pressure 6 bar; supply 50 Hz 3x380 V; grinding motor 1 kW; weight ~500 kg; dimensions 1500×1000×1800 mm. Equipment: coolant system. Achieves tight tolerances; suitable for woodworking, saw manufacturing and metalworking sectors.
| Saw blade diameter: | |
| from | 250 mm |
| up to | 1200 mm |
| Spacing: | |
| from | 15 mm/dent |
| up to | 100 mm/dent |
| Tooth height | 40 mm |
| Circular saw boring diameter | 22 - 210 mm |
| Clamping angle | 0 - 30 ° |
| Grinding angle | 0 - 15 ° |
| Diameter of grinding wheel | 200 / 250 mm |
| Max. grinding wheel width | 16 mm |
| Drilling cap. of grind.wheel | 25 mm |
| Feeds steps: | 4 |
| Coolant pressure | 6 bar |
| Voltage 50 Hz 3x | 380 Volt |
| grinding motor | 1 kW |
| Required power | kW |
| Machine's weight about | 500 kg |
| Overall dimensions machine: | |
| Length | 1500 mm |
| Width | 1000 mm |
| Height | 1800 mm |
