FEINTOOL HFA 400 is a Fine blanking machine designed for precision, high accuracy and reliability. Capacities: total capacity 4000 kN; vee-ring indenter pressure 1800 kN; back pressure 800 kN; pushing ram 300 kN; stripping 590 kN; tool faces sup. 800x800 mm, inf. 1000x810 mm; cutting speeds 5–50 mm/s, close traverse max 120 mm/s, return 135 mm/s, up to 150/230 c/min. Specs: 3x380 V 50 Hz, main motor 75 kW, total power 82 kW, weight ≈21700 kg, dimensions 5000x3300x3360 mm. Accessories: roll-feed, belt feeding, decoiler. Achieves tight tolerances for demanding industrial applications.
Technical specifications are subject to change without notice
| Total capacity | 4000 kN |
| Vee-ring indenter pressure | 1800 kN |
| Back pressure | 800 kN |
| pushing ram force | 300 kN |
| Stripping force | 590 kN |
| Tool clamping surface: | |
| superior: length | 800 mm |
| Width | 800 mm |
| inferior: length | 1000 mm |
| Width | 810 mm |
| Speeds: | |
| Cutting speed: | |
| from | 5 mm/s |
| up to | 50 mm/s |
| Close traverse speeds max. | 120 mm/s |
| Return traverse speeds | 135 mm/s |
| Number of strokes: | |
| up to | 150 / 230 c/min |
| Band width | 200 mm |
| Maximum thickness of material | 10 mm |
| Voltage 50 Hz 3x | 380 Volt |
| Main motor | 75 kW |
| Total power required | 82 kW |
| Machine's weight about | 21700 kg |
| Overall dimensions machine: | |
| Length | 5000 mm |
| Width | 3300 mm |
| Height | 3360 mm |
| Various accessories: | |
| Roll-feed | |
| Belt feeding | |
| Decoiler |
