HAAS VF-2 SSHE is a 3-axis machining center engineered for precision, high accuracy and reliability. Working capacities: table 914×356 mm, table load max 680 kg; travels X 762 mm, Y 406 mm, Z 508 mm; tool magazine 24+1, spindle nose BT40, speeds 0–12,000 rpm, rapid traverse 35 m/min. Main specs: spindle motor 22 kW; supply 50 Hz 3x400 V; machine weight ~3600 kg; dimensions L2357×W2235×H2654 mm. Accessories: 4th-axis preparation, coolant chip flushing, programmable/rotatable coolant nozzle, coolant system, Renishaw probing/workpiece measurement, chip conveyor, lamp, rigid tapping. Delivers tight tolerances; suitable for automotive, aerospace, medical, watchmaking and machine-tools industries.
| Number of axis simultaneous | 3 |
| Table length | 914 mm |
| Table width | 356 mm |
| Table load max. | 680 kg |
| Longitudinal travel (X-axis) | 762 mm |
| Transversal travel (y-axis) | 406 mm |
| Vertical travel (z axis) | 508 mm |
| Tool magazine number of tool places | 24+1 |
| Spindle nose: BT | 40 |
| Spindle speeds: | |
| stepless | |
| from | 0 t/min |
| up to | 12000 t/min |
| Rapid traverse: | 35 m/min |
| Voltage 50 Hz 3x | 400 Volt |
| Spindle motor | 22 kW |
| Machine's weight about | 3600 kg |
| Overall dimensions machine: | |
| Length | 2357 mm |
| Width | 2235 mm |
| Height | 2654 mm |
| Various accessories: | |
| Preparation 4the axis | |
| Coolant chip flushing | |
| Programmable and rotatable coolant nozzle | |
| Coolant system | |
| Measuring feeler gauge Renishaw | |
| Workpiece measurement Renishaw | |
| Chip conveyor | |
| Lamp | |
| Rigid tapping |
