KELLENBERGER 600 U
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
KELLENBERGER 600 U is a cylindrical grinder delivering high precision, accuracy and reliability. Centre height 125 mm, distance between centres 600 mm; grinding wheel Ø350×50 mm, bore 127 mm; wheel head 270°; workpiece spindle 360° 20–400 t/min; wheel speeds 4 steps 1500–3600 t/min. Table tilt 10°, table speed up to 6 m/min. Supply 50 Hz 3×380 V; external grinding wheel motor 4 CV. Machine weight ≈2200 kg; dimensions 2200×1750×1600 mm. Equipment: coolant system, lamp, tailstock. Achieves tight tolerances for applications requiring high precision.
Technical specifications are subject to change without notice
| Centre height | 125 mm |
| Distance between centres | 600 mm |
| Grinding wheel: | |
| Diameter | 350 mm |
| Width | 50 mm |
| Bore | 127 mm |
| Grinding wheel speeds: | |
| number (steps) | 4 |
| from | 1500 t/min |
| up to | 3600 t/min |
| Angular displacement | 270 ° |
| Work piece spindle head: | |
| speeds: | |
| stepless | |
| from | 20 t/min |
| up to | 400 t/min |
| rotatable | 360 ° |
| Spindle taper | 3 CM |
| Taper in tailstock: | 3 CM |
| Table angular displacement | 10 ° |
| Table speed: | |
| stepless | |
| up to | 6 m/min |
| Voltage 50 Hz 3x | 380 Volt |
| External Grinding wheel motor | 4 CV |
| Machine's weight about | 2200 kg |
| Overall dimensions machine: | |
| Length | 2200 mm |
| Width | 1750 mm |
| Height | 1600 mm |
| Various accessories: | |
| Coolant system | |
| Lamp | |
| Tailstock |
