PETER WOLTERS AC 500
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
PETER WOLTERS AC 500 is a lapping / fine grinding machine engineered for precision, high accuracy and reliability. Two-wheel execution, max. wheel diameter 440 mm. Speeds upper wheel: 2 steps 56–113 t/min; lower wheel: 2 steps 50–100 t/min; work-piece drive: 3 steps 20–65 t/min. Loading of upper wheel up to 250 kg. Voltage 50 Hz 3x 380 V; air connect 5 bar; main motor 1.0/1.4 kW; work-piece mechanism 0.5/0.9 kW; weight approx. 800 kg; overall dims L1700×W1250×H1750 mm. Allows achievement of tight tolerances; typical applications: automotive, watchmaking, toolmaking, aerospace, medical.
| Execution: | |
| two wheels | |
| Max. wheel diameter | 440 mm |
| Lap plate: | |
| Speeds upper wheel: | |
| number (steps) | 2 |
| from | 56 t/min |
| up to | 113 t/min |
| Speeds lower wheel: | |
| number (steps) | 2 |
| from | 50 t/min |
| up to | 100 t/min |
| Speeds work-piece mechanism: | |
| number (steps) | 3 |
| from | 20 t/min |
| up to | 65 t/min |
| Loading of the upper wheel: | |
| up to | 250 kg |
| Voltage 50 Hz 3x | 380 Volt |
| Air connect | 5 bar |
| Motor capacity: | |
| Main motor | 1.0 / 1.4 kW |
| work-piece mechanism | 0.5 / 0.9 kW |
| Machine's weight about | 800 kg |
| Overall dimensions machine: | |
| Length | 1700 mm |
| Width | 1250 mm |
| Height | 1750 mm |
