| Table length | 1200 mm |
| Table width | 270 mm |
| Number of T-channels | 3 |
| T-channel width | 16 mm |
| Distance of the T-slots | 65 mm |
| Longitudinal travel (X-axis) | 760 mm |
| Transversal travel (y axis) | 340 mm |
| Vertical travel (z axis) | 410 mm |
| Spindle speeds: | |
| number (steps) | 12 |
| from | 35 t/min |
| up to | 1600 t/min |
| Taper in spindle | 40 ISO |
| Voltage 50 Hz 3x | 380 Volt |
| Spindle motor | 2.2 kW |
| Machine's weight about | 2000 kg |
| Overall dimensions machine: | |
| Length | 2000 mm |
| Width | 1800 mm |
| Height | 1800 mm |
