MOORE CATMUR 2C is a jig grinder for precision, high accuracy and reliable performance. Capacities: table 610×280 mm; travels X450 Y280 Z250 mm; max grinding Ø127 mm; spindle-nose stroke 340 mm. Specs: spindle max 160000 t/min; weight ≈1660 kg; dims L1650×W1085×H2000 mm. Achieves tight tolerances; typical sectors: automotive, watchmaking, machine tools, aerospace, medical.
| 1 column execution | |
| Table length | 610 mm |
| Table width | 280 mm |
| Longitudinal travel (X-axis) | 450 mm |
| Transversal travel (y-axis) | 280 mm |
| Vertical travel (z axis) | 250 mm |
| Max. grinding diameter | 127 mm |
| Stroke of spindle-nose | 340 mm |
| Machine's weight about | 1660 kg |
| Overall dimensions machine: | |
| Length | 1650 mm |
| Width | 1085 mm |
| Height | 2000 mm |
| Various accessories: | |
| Grinding motors: | |
| max. speed | 160000 t/min |
