METALLKRAFT MSBM 1520/35 PRO
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
METALLKRAFT MSBM 1520/35 PRO is a motorised swivel bending machine for precision, high accuracy and reliability. Working width 1520 mm; max bending: steel 4 mm, VA-steel 3 mm, aluminium 4 mm; passage 200 mm. Top/bottom drives 1 kW each; total 4 kW; weight ~2700 kg; dims L2345×W1100×H1560 mm. Delivers tight tolerances; typical applications: automotive, machine tools, aerospace, medical, watchmaking.
| Working width | 1520 mm |
| Max. bending capacity steel | 4 mm |
| Max. bending capacity VA-steel | 3 mm |
| Max. bending capacity aluminium | 4 mm |
| manual | |
| Passage between upper and lower cheek max. | 200 mm |
| Required power top clamping bar | 1 kW |
| Required power lower clamping bar | 1 kW |
| Total required power | 4 kW |
| Machine's weight about | 2700 kg |
| Overall dimensions machine: | |
| Length | 2345 mm |
| Width | 1100 mm |
| Height | 1560 mm |
