STUDER FS 71 is a cylindrical grinder engineered for precision, high accuracy and reliable performance. Capacities: max cutter Ø 250 mm, max width 175 mm, max grinding wheel Ø 175 mm; table 900×750 mm. Specs: 9 wheel speeds 2,750–7,660 rpm; 50 Hz 3x380 V; drive 0.5 CV; weight ~650 kg; overall 1400×1200×1500 mm. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical.
| Max. milling cutter diameter | 250 mm |
| Max. cutter-grinding width | 175 mm |
| Max. grinding wheel diamter | 175 mm |
| Table size: | |
| Length | 900 mm |
| Width | 750 mm |
| Grinding wheel speeds: | |
| number (steps) | 9 |
| from | 2750 t/min |
| up to | 7660 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Drive | 0.5 CV |
| Machine's weight about | 650 kg |
| Overall dimensions machine: | |
| Length | 1400 mm |
| Width | 1200 mm |
| Height | 1500 mm |
