DECKEL S 11 is a Tool and cutter grinder for precision, high accuracy and reliability. Capacities: centre height 300 mm, distance between centres 380 mm, table 500×180 mm; max grinding Ø 238/620 mm; max wheel 125 mm; transversal 220 mm; crosswise 100 mm; longitudinal 190 mm; vertical/head 325 mm; axes 360°. Specs: grinding spindle 2 steps 400–8000 t/min; spindle motor 1.3 kW; voltage 3×380 V 50 Hz; total 2 kVA; weight ~500 kg; dims 1100×800×1760 mm. Achieves tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace, medical.
| Centre height | 300 mm |
| Distance between centres | 380 mm |
| Table length | 500 mm |
| Table width | 180 mm |
| Max. grinding diameter | 238 / 620 mm |
| Max. grinding wheel diamter | 125 mm |
| Longitudinal way of table | mm |
| Transversal way of the table | 220 mm |
| Axial motion: | |
| Crosswise | 100 mm |
| Longitudinal | 190 mm |
| Vertical | 325 mm |
| Vertical adjustment of grinding head | 325 mm |
| Slewing range of grinding head: | |
| horizontal | 360 ° |
| vertical | 360 ° |
| rotary axis of the grinding spindle head | 360 ° |
| Grinding spindle speeds: | |
| number (steps) | 2 |
| from | 400 t/min |
| up to | 8000 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Grinding spindle motor | 1.3 kW |
| Total power required | 2 kVA |
| Machine's weight about | 500 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 800 mm |
| Height | 1760 mm |
