| Swing over cross-slide | 230 mm |
| Swing over bed | 420 mm |
| Spindle hole | 51 mm |
| Turning length | 1000 mm |
| Spindle speeds: | |
| number (steps) | 2 |
| stepless | |
| from | 10 t/min |
| up to | 3000 t/min |
| Taper in tailstock: | |
| Morse taper | 4 CM |
| Rapid traverse: | 5 / 10 m/min |
| Spindle motor | 11/9 kW |
| Voltage 50 Hz 3x | 400 Volt |
| Machine's weight about | 3000 kg |
| Overall dimensions machine: | |
| Length | 3420 mm |
| Width | 1925 mm |
| Various accessories: | |
| 3-jaw chuck | |
| Lamp | |
| Tailstock | |
| Coolant system | |
| Chip conveyor | |
| Toolholders |
