NOVOTEC SD-1014 is a Start hole eroding machine designed for precision, high accuracy and reliability. 3 axes; workpiece up to 450×300×300 mm; table load max 150 kg; travels X 350 mm, Y 250 mm, Z 350 mm; electrode diameter 0.3–3 mm. Dielectric unit 20 l; power 4 kW; machine weight ≈900 kg; overall dimensions 1130×1110×2330 mm. Enables tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical.
| Number of axis total | 3 |
| Dimension of the workpice: | |
| Length | 450 mm |
| Width | 300 mm |
| Height | 300 mm |
| Table load max. | 150 kg |
| Longitudinal traverse (X-axis) | 350 mm |
| Cross traverse (Y-axis) | 250 mm |
| Height adjustment (Z-axis) | 350 mm |
| Electrode diameter | 0.3 - 3 mm |
| Dielectric aggregate: | |
| Contents | 20 l |
| Power | 4 kW |
| Machine's weight about | 900 kg |
| Overall dimensions machine: | |
| Length | 1130 mm |
| Width | 1110 mm |
| Height | 2330 mm |
