AGIE CHARMILLES ROBOFORM 550 is a Spark eroder, engineered for high precision, superior accuracy and dependable performance. Table 750×600 mm, table load max 1600 kg; workpiece up to 1200×850×400 mm; travels X 600 mm, Y 400 mm, Z 450 mm; max electrode weight 100 kg. Supply 3×400 V 50 Hz; machine weight ≈4500 kg; overall dimensions 3150×2750×2960 mm. Achieves tight tolerances for molds and precision parts; typical sectors: automotive, watchmaking, machine tools, aerospace, medical
| Table length | 750 mm |
| Table width | 600 mm |
| Dimension of the workpice: | |
| Length | 1200 mm |
| Width | 850 mm |
| Height | 400 mm |
| Table load max. | 1600 kg |
| Longitudinal traverse (X-axis) | 600 mm |
| Cross traverse (Y-axis) | 400 mm |
| Height adjustment (Z-axis) | 450 mm |
| max. electrode weight | 100 kg |
| Voltage 50 Hz 3x | 400 Volt |
| Machine's weight about | 4500 kg |
| Overall dimensions machine: | |
| Length | 3150 mm |
| Width | 2750 mm |
| Height | 2960 mm |
| Lamp |
