AGATHON 150 A is a tool grinding machine engineered for precision, high accuracy and reliability. Working capacities: grinding wheel Ø150 mm, width 20 mm, bore 20 mm; spindle speeds up to 2500 t/min; tool orthogonal clearance max 26°; clamping range for tools Width 32 mm Height 32 mm. Main specs: 50 Hz 3x 380 V, power 1.0 CV; machine weight about 300 kg; overall dimensions L820×W564×H1215 mm. Accessories: inclinable tool holder, coolant system and lamp. Designed to achieve tight tolerances for automotive, machine tools, aerospace, medical and watchmaking sectors.

Technical specifications are subject to change without notice
