    BTM 320 - 420A/CNC






    Download technical sheet (PDF)








            BTM 320 - 420A/CNC is a Band saw engineered for precision, high accuracy and industrial reliability. Capacity: round and square cuts up to 410 mm; stepless cutting speed 10–100 m/min; table inclination right 60°. Key specs: roll diameter 450 mm; band length 5300 mm; band width 34 mm; band thickness 1 mm; vice pressure 3–25 bar; 50 Hz 3x380 V supply; saw motor 2 kW; weight ~2300 kg; footprint L3250×W1910×H2100 mm. Delivers tight tolerances; suited to automotive, tooling, aerospace, medical and watchmaking sectors.


| Cut range: round up to | 410 mm |
| Square | 410 mm |
| hydraulic | |
| Automatic | |
| Cutting speed: | |
| stepless | |
| from | 10 m/min |
| up to | 100 m/min |
| Table inclination right side | 60 ° |
| Roll diameter | 450 mm |
| Band length | 5300 mm |
| Band width | 34 mm |
| Sheet thickness | 1 mm |
| Vice pressure max. | 3 - 25 bar |
| Voltage 50 Hz 3x | 380 Volt |
| Saw motor driving power | 2 kW |
| Machine's weight about | 2300 kg |
| Overall dimensions machine: | |
| Length | 3250 mm |
| Width | 1910 mm |
| Height | 2100 mm |
