AGATHON 150 SL20 D is a Centreless grinding machine designed for high precision, excellent accuracy and reliable production performance. Grinding capacity up to a maximum diameter of 10 mm; grinding wheel width 50 mm; main wheel new diameter 150 mm (bore 50 mm), regulating wheel new diameter 100 mm (bore 40 mm), width 50 mm. Spindle speeds up to 6000 t/min; regulating spindle stepless from 15 to 150 t/min; main motor 2.0 CV; machine weight approx. 650 kg; dimensions L1800×W1400×H1600 mm. Fitted with a paper filtration system. Enables tight tolerances; typical applications include automotive, watchmaking, machine tools, aerospace and medical.

Technical specifications are subject to change without notice
