LORENZ is a coil straightener and decoiler with precision, high accuracy and reliability. Capacities: inner coil Ø 460–520 mm, outer Ø up to 1900 mm; max. coil weight 7500 kg; max. bandwidth 620 mm; sheet thickness 1–7 mm. Main specs: 9 straightening rolls, roll Ø 50 mm. Delivers tight tolerances; typical sectors: automotive, machine tools, aerospace, medical.
| Decoiler: | |
| Inner coil diameter | 460 - 520 mm |
| Outer coil diameter | 1900 mm |
| Max. Coil weight | 7500 kg |
| Band thickness max. | 620 mm |
| Coil straightening machine: | |
| Number of rolls | 9 |
| Roll diameter | 50 mm |
| Max. bandwidth | 620 mm |
| Sheet thickness: | |
| from | 1 mm |
| up to | 7 mm |
