ACIERA F 3 is a universal milling machine engineered for precision, high accuracy and reliable performance. Working capacities: table 600×190 mm; travels X 300 mm, Y 135 mm, Z 300 mm. Main specs: spindle taper W20 vertical/horizontal; 8 speeds from 100 to 2000 t/min; 8 feed steps 12.0–232 mm/min; 50 Hz 3x 380 V; motor 2.0 CV; weight ≈620 kg; overall 1100×900×1600 mm. Accessories: motorized vertical table adjustment and lamp. Suited to achieve tight tolerances; typical applications include automotive, watchmaking, machine tools, aerospace and medical.
| Table length | 600 mm |
| Table width | 190 mm |
| Longitudinal travel (X-axis) | 300 mm |
| Transversal travel (y axis) | 135 mm |
| Vertical travel (z axis) | 300 mm |
| Spindle speeds: | |
| number (steps) | 8 |
| from | 100 t/min |
| up to | 2000 t/min |
| Taper in spindle: | |
| Vertical | W20 |
| Horizontal | W20 |
| Feeds steps: | 8 |
| longitudinal from | 12.0 mm/min |
| up to | 232 mm/min |
| Voltage 50 Hz 3x | 380 Volt |
| Motor output | 2.0 CV |
| Machine's weight about | 620 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 900 mm |
| Height | 1600 mm |
| Various accessories: | |
| Motorized table adjustment vertically | |
| Lamp |
