ESSA RE 8 is an Excentric press, precise, highly accurate and reliable. Capacities: Pressure 4 to; circular table Ø220 mm, table hole Ø80 mm; 50-150 c/min; distance between columns (front) 230 mm; fixed stroke 27 mm; slide adjustment 40 mm; tool height max 148 mm. Main specs: Voltage 50 Hz 3x 400 Volt; Power 0.75 CV; weight ~700 kg; overall L1100 x W900 x H1600 mm. Accessories: safety device, lamp, sound insulation cabin. Delivers tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors.
| Pressure | 4 to |
| Execution: number of columns | 2 |
| Machine frame: fixed | |
| Circulary table diameter | 220 mm |
| diameter | 80 mm |
| Number of strokes: | |
| from | 50 c/min |
| up to | 150 c/min |
| Adjustment of the slide | 40 mm |
| Fixed stroke | 27 mm |
| Tool height | 148 mm |
| Distance between columns: | |
| front | 230 mm |
| Voltage 50 Hz 3x | 400 Volt |
| Power | 0.75 CV |
| Machine's weight about | 700 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 900 mm |
| Height | 1600 mm |
| Various accessories: | |
| Security/savety device | |
| Lamp | |
| Sound insulation cabin |
