AGIE CHARMILLES ROBOFIL 2020SI
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
AGIE CHARMILLES ROBOFIL 2020SI is a wire cutting machine with high precision, engineered for excellent accuracy and reliability. Working capacities: max. workpiece dimensions L 900 × W 520 × H 270 mm; table load max. 500 kg; longitudinal travel (X) 320 mm, cross travel (Y) 220 mm, vertical travel (Z) 270 mm; taper cut ±30°; electrode wire diameter from 0.25 mm. Main specifications: overall machine dimensions L 3400 × W 2400 × H 2300 mm. Enables tight tolerances and is suitable for automotive, watchmaking, machine tools, aerospace and medical sectors
| Max. dimensions of work piece: | |
| Length | 900 mm |
| Width | 520 mm |
| Height | 270 mm |
| Table load max. | 500 kg |
| Longitudinal traverse (X-axis) | 320 mm |
| Cross traverse (Y-axis) | 220 mm |
| Vertical travel (Z axis) | 270 mm |
| Taper-cut +/- | 30 ° |
| Diameter of electrode wire: | |
| from | 0.25 mm |
| up to | mm |
| Overall dimensions machine: | |
| Length | 3400 mm |
| Width | 2400 mm |
| Height | 2300 mm |
