GHIRINGHELLI M100SP400
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
GHIRINGHELLI M100SP400 is a Centreless grinding machine of high precision, engineered for superior accuracy and operational reliability. Capacities: min grinding diameter 1 mm, max 40 mm; infeed grinding 95 mm; grinding wheel Ø new 400 mm (used 300 mm) width 110 mm, bore 203 mm; regulating wheel Ø new 305 mm (used 220 mm) width 20 mm, swivel -6°. Technical specs: peripheral speed 50 m/s (2353 rpm new, 3183 rpm worn); stepless regulating spindle 0–140 rpm; dressing speed 250 rpm; supply 3x 400 V 50 Hz, air 5 bar; total power 20 kW; weight ~2600 kg; footprint L3456×W2960×H2235 mm. Achieves tight tolerances; ideal for automotive, aerospace, watchmaking, medical and machine tool industries.
| Min. grinding diameter | 1 mm |
| Max. grinding diameter | 40 mm |
| Max. workpiece length | |
| for infeed grinding | 95 mm |
| Grinding wheel: | |
| diameter new wheel | 400 mm |
| diameter used wheel | 300 mm |
| Width | 110 mm |
| Bore | 203 mm |
| Speed with new grinding wheel | 2353 t/min |
| Speed with abraded grinding wheel | 3183 t/min |
| Peripheral speed | 50 m/s |
| Regulating spindle: | |
| diameter new wheel | 305 mm |
| diameter used wheel | 220 mm |
| Width | 20 mm |
| Swivelling range | -6 ° |
| Speeds: | |
| stepless | |
| from | 0 t/min |
| up to | 140 t/min |
| Dressing speed | 250 t/min |
| Voltage 50 Hz 3x | 400 Volt |
| Air connect | 5 bar |
| Total power required | 20 kW |
| Machine's weight about | 2600 kg |
| Overall dimensions machine: | |
| Length | 3456 mm |
| Width | 2960 mm |
| Height | 2235 mm |
| Various accessories: |
