FMB Turbo 5-42
Type: Turbo 5-42
Manufacturer: FMB
Stock: 020602
Download technical sheet (PDF)
FMB Turbo 5-42 is a bar feeder/loader of high precision, engineered for superior accuracy and reliability. Capacity: round bar diameter 5–42 mm; bar length max 3200 mm; minimum remnant 530 mm; feed range 0–400 mm/s. Key specs: max feed force 550 N; voltage 50 Hz 3x 400 V; power 2 kW; compressed air 6 bar; overall dimensions L 4700 × W 915 × H 1200 mm. Enables tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical.

Execution:
   left
Bar diameter round up 5 mm
   up to 42 mm
Length of bars max. 3200 mm
Outstanding length min. 530 mm
Feed range 0 - 400 mm/s
Max. Feed force 550 N
Voltage 50 Hz 3x 400 Volt
Power 2 kW
Compressed air from 6 bar
Overall dimensions machine:
Length 4700 mm
Width 915 mm
Height 1200 mm
