| Min. internal grinding diameter | 1 mm |
| Max. internal grinding diameter | 30 mm |
| Grinding depth | 1 - 100 mm |
| Centre height | 185 mm |
| Distance between centres | 200 mm |
| Workpiece spindle speeds: | |
| number (steps) | 3 |
| from | 550 t/min |
| up to | 800 t/min |
| Spindle hole | 20 mm |
| Taper in spindle: | 25 W |
| Grinding spindle speeds: | |
| from | 30000 t/min |
| up to | 45000 t/min |
| Grinding table travel: | |
| min. | 1 mm |
| max | 100 mm |
| Table speeds: | |
| stepless | |
| up to | 5 m/min |
| Voltage 50 Hz 3x | 380 Volt |
| Machine's weight about | 610 kg |
| Overall dimensions machine: | |
| Length | 1450 mm |
| Width | 760 mm |
| Height | 1600 mm |
| Various accessories: | |
| Redressing device | |
| Coolant system |
