| Centre height | 102 mm |
| Distance between centres | 375 mm |
| Swing over cross-slide | 120 mm |
| Swing over bed | 200 mm |
| Inner taper type | W25 |
| number (steps) | 12 |
| from | 45 t/min |
| up to | 2800 t/min |
| Taper in tailstock: | 2 CM |
| Feeds: | |
| Voltage 50 Hz 3x | 380 Volt |
| Overall dimensions machine: | |
| Length | 2200 mm |
| Width | 800 mm |
| Height | 1650 mm |
| Various accessories: | |
| Working bench: | |
| Length | 2150 mm |
| Width | 770 mm |
| Height | 900 mm |
| Driving system for milling and grinding attachment | |
| 3-jaw chuck diameter | 100 mm |
| Drilling tailstock | |
| Chip protector |
