| Table length | 700 mm |
| Table width | 370 mm |
| Drill capacity in steel | 22 mm |
| Drill capacity in cast-iron | 24 mm |
| Depth of throat | 300 mm |
| Drill depth (spindle stroke) | 120 mm |
| Spindle speeds: | |
| from | 250 t/min |
| up to | 4000 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Spindle motor | 2 CV |
| Machine's weight about | 990 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 600 mm |
| Height | 2100 mm |
| Various accessories: | |
| Digital readout number of axis: | 2 |
| Tool storage | |
| Lamp | |
| Motorized table adjustment |
ACIERA 22 V is a pillar drilling machine built for precision, high accuracy and reliability. Capacities: drilling in steel Ø22 mm, in cast‑iron Ø24 mm; spindle stroke 120 mm; throat 300 mm; table 700×370 mm. Specs: spindle speeds 250–4000 t/min; spindle motor 2 CV; supply 3×380 V 50 Hz; weight ≈990 kg; dims L1100×W600×H2100 mm. Equipment: 2‑axis digital readout, tool tray, lamp, motorized table adjustment. Suited to achieving tight tolerances in automotive, machine tools, aerospace, medical and watchmaking.
Technical specifications are subject to change without notice
