SCHAUBLIN 140 CNC is a CNC turning lathe offering high precision, accuracy and reliability. Capacities: turning Ø 300 mm; spindle hole 51 mm; bar Ø 24/36 mm; travels Z 370 mm, X 210 mm; turret 1×12 driven tools. Key specs: 3 axes; taper A2‑5 (VDI30); 30–6000 rpm (stepped), stepless 50–5000 rpm; driven tool power 2.2/3.7 kW; C‑axis res. 0.001°; feeds 1–10000 mm/min; rapid 10 m/min; air 6 bar; 380V 50Hz; weight ~3000 kg; footprint 2530×1400×1840 mm. Accessories: lamp, 130 l coolant system, foot pedal. Delivers tight tolerances; suited for automotive, watchmaking, machine tools, aerospace and medical components.
| Number of axis total | 3 |
| Taper in spindle | A2-5 |
| Spindle hole | 51 mm |
| Turning diameter | 300 mm |
| Bar diameter with collet | 24 / 36 mm |
| Carriage: | |
| Longitudinal travel (Z-axis) | 370 mm |
| Cross travel (x-axis) | 210 mm |
| Turret slide: number | 1 |
| Driven tools turret 1 | 12 |
| Driven tools turret | 12 |
| Spindle speeds | 30 - 6000 t/min |
| Power of driven tools | 2.2 / 3.7 kW |
| Spindle nose: VDI | 30 |
| Main spindle: | |
| C axis (spindle,resolution) | 0.001 ° |
| Spindle speeds: | |
| stepless | |
| from | 50 t/min |
| up to | 5000 t/min |
| Feeds: | |
| stepless | |
| longitudinal from | 1 mm/min |
| up to | 10000 mm/min |
| transversal from | 1 mm/min |
| up to | 10000 mm/min |
| Rapid traverse: | 10 m/min |
| Air connect | 6 bar |
| Voltage 50 Hz 3x | 380 Volt |
| Machine's weight about | 3000 kg |
| Overall dimensions machine: | |
| Length | 2530 mm |
| Width | 1400 mm |
| Height | 1840 mm |
| Various accessories: | |
| Lamp | |
| Coolant system | 130 l |
| Foot pedal |
