DECKEL S 1 is a Tool and cutter grinder engineered for precision, high accuracy and reliability. Working capacities: centre height 95 mm; distance between centres 250 mm; max. grinding diameter 130 mm; table 450 x 175 mm; longitudinal travel 260 mm, transverse 50 mm, vertical 50 mm; table swivels 360°; horizontal 360°/vertical 220°. Technical specs: speeds 3,750–7,500 t/min (2 steps); voltage 50 Hz 3x 380 V; total power 1 CV; weight approx. 450 kg; footprint L1000 x W600 x H1400 mm. Achieves tight tolerances; typical applications include automotive, watchmaking, machine tools, aerospace and medical.
| Centre height | 95 mm |
| Distance between centres | 250 mm |
| Table length | 450 mm |
| Table width | 175 mm |
| Max. grinding diameter | 130 mm |
| Longitudinal way of table | 260 mm |
| Transversal way of the table | 50 mm |
| Vertical adjustment of the table | 50 mm |
| Table swivels | 360 ° |
| horizontal | 360 ° |
| vertical | 220 ° |
| number (steps) | 2 |
| from | 3750 t/min |
| up to | 7500 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Total power required | 1 CV |
| Machine's weight about | 450 kg |
| Overall dimensions machine: | |
| Length | 1000 mm |
| Width | 600 mm |
| Height | 1400 mm |
