CINCINNATI PE 10 / NE 23
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
| Number of drill-heads | 2 |
| Drill depth (spindle stroke) | 100 mm |
| Table length | 1350 mm |
| Table width | 290 mm |
| Taper in spindle | 2 CM |
| Depth of throat | 235 mm |
| Drill head 1: | PE 10 |
| Drill capacity | 10 mm |
| Spindle speeds: | |
| number (steps) | 10 |
| from | 660 t/min |
| up to | 12000 t/min |
| Drill head 2: | NE 23 |
| Drill capacity | 23 mm |
| Spindle speeds: | |
| number (steps) | 8 |
| from | 220 t/min |
| up to | 4000 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Machine's weight about | 300 kg |
| Overall dimensions machine: | |
| Length | 2000 mm |
| Width | 900 mm |
| Height | 1600 mm |
| Various accessories: | |
| Vice: width | 100 mm |
| Drill chuck | 2x |
| Adjustable depth stop |
CINCINNATI PE 10 / NE 23 is a multi-head drill engineered for precision, high accuracy and reliable production performance. It features 2 drill heads with 100 mm spindle stroke; drill capacity PE 10: 10 mm, NE 23: 23 mm; table 1350 x 290 mm and throat 235 mm. Key specs: PE 10 with 10 steps 660–12,000 rpm, NE 23 with 8 steps 220–4,000 rpm; spindle taper 2 CM; voltage 50 Hz 3x380 V; machine weight ~300 kg; overall L200 x W850 x H1700 mm. Equipment: vice (jaw width 100 mm), 2 drill chucks and adjustable depth stop. Suited to achieve tight tolerances for automotive, aerospace, machine tools and precision engineering.
Technical specifications are subject to change without notice
