SCHAUBLIN 102-80 is a Toolmakers lathe built for precision, high accuracy and reliability. Capacities: centre height 102 mm; distance between centres 375 mm; swing over cross-slide 120 mm; swing over bed 200 mm; inner taper type 20 W. Specs: 12 steps from 45 to 2800 t/min; tailstock taper 2 CM; 50 Hz 3x380 V supply; spindle motor 0.5 CV; machine weight approx. 300 kg; overall L1200 x W700 x H1500 mm. Equipment: base-mounted on cast iron, lamp, 4-jaw chuck, driving plate, drilling tailstock, drill chuck, hand rest, fixed steady. Suited to tight tolerances in watchmaking, toolrooms, aerospace, medical and automotive.

Technical specifications are subject to change without notice
