ACIERA 22 VR is a pillar drilling machine engineered for precision work, delivering high accuracy and reliable performance. Working capacities: table 700 x 370 mm; clamping surface 580 x 280 mm; drill capacity in steel 22 mm, in cast-iron 24 mm; throat depth 300 mm; drill depth (spindle stroke) 120 mm; spindle head adjustment 300 mm; travels X 330 mm, Y 210 mm, Z 350 mm. Main specs: spindle taper MT3; stepless spindle speeds 40–3600 t/min; spindle motor 1.0 / 1.5 CV; supply 50 Hz 3x 380 V; weight ≈990 kg; overall dims 900×1000×1800 mm. Accessories: 2-axis digital readout, preparation for coolant, lamp, quick-change device A-30, adjustable depth stop, motorized table adjustment. Enables tight tolerances; suited for automotive, watchmaking, machine tool, aerospace and medical applications.
| Table length | 700 mm |
| Table width | 370 mm |
| Clamping surface: | |
| Length | 580 mm |
| Width | 280 mm |
| Drill capacity in steel | 22 mm |
| Drill capacity in cast-iron | 24 mm |
| Taper in spindle: MT | 3 |
| Depth of throat | 300 mm |
| Drill depth (spindle stroke) | 120 mm |
| Spindle head adjustment | 300 mm |
| Table travels: | |
| Longitudinal travel (X-axis) | 330 mm |
| Transversal travel (y-axis) | 210 mm |
| Vertical travel (z axis) | 350 mm |
| Spindle speeds: | |
| stepless | |
| from | 40 t/min |
| up to | 3600 t/min |
| Feeds: | |
| Voltage 50 Hz 3x | 380 Volt |
| Spindle motor | 1.0 / 1.5 CV |
| Machine's weight about | 990 kg |
| Overall dimensions machine: | |
| Length | 900 mm |
| Width | 1000 mm |
| Height | 1800 mm |
| Various accessories: | |
| Digital readout number of axis: | 2 |
| Preparation for coolant device | |
| Lamp | |
| Quick change device | A-30 |
| Adjustable depth stop | |
| Motorized table adjustment |
