ACIERA F 1 is a Universal milling machine, designed for precision machining with high accuracy and reliability. Travels: X 100 mm, Y 75 mm, Z 150 mm. Spindle 6 steps 125–4000 t/min, taper 12 W. Voltage 50 Hz 3x 380 V, motor output 0.3 CV. Weight ≈120 kg; dimensions L700×W600×H1400 mm. Accessories: vice (jaw width 60 mm), steady, set of collets. Delivers tight tolerances; typical applications include watchmaking, machine tools, aerospace, medical and automotive.
| Longitudinal travel (X-axis) | 100 mm |
| Transversal travel (y axis) | 75 mm |
| Vertical travel (z axis) | 150 mm |
| Spindle speeds: | |
| number (steps) | 6 |
| from | 125 t/min |
| up to | 4000 t/min |
| Taper in spindle: | 12 W |
| Voltage 50 Hz 3x | 380 Volt |
| Motor output | 0.3 CV |
| Machine's weight about | 120 kg |
| Overall dimensions machine: | |
| Length | 700 mm |
| Width | 600 mm |
| Height | 1400 mm |
| Various accessories: | |
| Vice: width | 60 mm |
| Steady | |
| Set of collets |
