MIKRON UME 560 is a CNC milling machine of high precision, designed for outstanding accuracy and reliability. Capacity: table 900×530 mm; travels X 560 mm, Y 500 mm, Z 400 mm. Main specs: spindle nose ISO SK40 DIN 69871; spindle speeds horiz./vert. 5–5000 t/min stepless; feeds 1–8000 mm/min (X/Y/Z); rapid traverse 10 m/min; power 50 Hz 3x 380 V; machine weight ≈3350 kg; overall L 3930 (2625) × W 2650 × H 2140 mm. Accessories: electronic hand‑held control, coolant system. Delivers tight tolerances; suited to automotive, aerospace, medical, watchmaking and machine tool sectors
| Table length | 900 mm |
| Table width | 530 mm |
| Longitudinal travel (X-axis) | 560 mm |
| Transversal travel (y axis) | 500 mm |
| Vertical travel (z axis) | 400 mm |
| Spindle speeds: | |
| stepless | |
| horizontal from | 5 t/min |
| up to | 5000 t/min |
| vertical from | 5 t/min |
| up to | 5000 t/min |
| Spindle nose: ISO | SK 40 DIN 69871 |
| Feeds: | |
| longitudinal from | 1 mm/min |
| up to | 8000 mm/min |
| transversal from | 1 mm/min |
| up to | 8000 mm/min |
| vertical from | 1 mm/min |
| up to | 8000 mm/min |
| Rapid traverse: | 10 m/min |
| Voltage 50 Hz 3x | 380 Volt |
| Machine's weight about | 3350 kg |
| Overall dimensions machine: | |
| Length | 3930 (2625) mm |
| Width | 2650 mm |
| Height | 2140 mm |
| Various accessories: | |
| Electronic hand held control | |
| Coolant system |
