017178 - AGATHON Optiset 2
Download technical sheet (PDF)
Message us on WhatsApp
| Longitudinal way of table | 250 mm |
| Vertical adjustment of grinding head | 100 mm |
| Transversal way of grinding head | 100 mm |
| Slewing range of grinding head: | |
| vertical | - 15 ° |
| Grinding spindle speeds: | |
| stepless | |
| from | 6000 t/min |
| up to | 50000 t/min |
| Voltage 50 Hz 3x | 400 Volt |
| Grinding spindle motor | 0.660 kW |
| Machine's weight about | 500 kg |
| Overall dimensions machine: | |
| Length | 800 mm |
| Width | 800 mm |
| Height | 1300 mm |
| Various accessories: | |
| Lamp | |
| Microscope | |
| Microscopeholder | |
| Work piece holder | |
| Grinding stroke drive |
