DISKUS DD 300 So
Special Price
CHF 15 000
Special offer machines are sold as-is, without any warranty or inspection from us.
Need Assistance? Just WhatsApp Us!
DISKUS DD 300 So is a Double surface grinder designed for precision, high accuracy and reliable performance. Capacities: max work-piece height 80 mm; 2 grinding heads; grinding wheel Ø outside 300 mm, inside 233 mm, width/height 50 mm; horizontal arrangement; driving plate speed 29.6–192 mm/s. Technical specs: grinding wheel speeds from 1530 t/min up to 24 m/s; voltage 380 V; machine weight ≈2500 kg; overall L3050×W1400×H1600 mm. Equipment: measuring instrument PRETEC. Achieves tight tolerances; suited to precision sectors (automotive, machine tools, aerospace, medical, watchmaking).
| Max. work-piece height | 80 mm |
| Number of grinding heads | 2 |
| Arrangement: | |
| horizontal | |
| Work-piece driving plate: | |
| Grinding wheel: | |
| outside diameter | 300 mm |
| inside diameter | 233 mm |
| Width / height | 50 mm |
| Grinding wheel speeds: | |
| from | 1530 t/min |
| up to | 24 m/s |
| Work-piece advance: | |
| Speed of the work-piece | |
| driving plate: | 29.6 - 192 mm/s |
| Voltage | 380 Volt |
| Machine's weight about | 2500 kg |
| Overall dimensions machine: | |
| Length | 3050 mm |
| Width | 1400 mm |
| Height | 1600 mm |
| Various accessories: | |
| Measuring instrument | PRETEC |
| Workpiece loader |
