SCHÜTTE SF 42 is a Multi-spindle turning lathe engineered for high precision, excellent accuracy and dependable performance. Key capacities: 6 spindles; round bar capacity 42 mm, square 30 mm, hexagon 36 mm; max. long slide stroke 125 mm; cycle time 1–280 s. Main specifications: 49 spindle steps, 315–2240 rpm; 50 Hz 3x 380 V supply; 22 kW power; machine weight ≈10000 kg; footprint L6500 × W1400 × H2100 mm. Equipment: provision for bar feeder and chip conveyor. Achieves tight tolerances; ideal for automotive, watchmaking, machine tools, aerospace and medical sectors
| Number of spindles | 6 |
| Capacity round bar | 42 mm |
| Capacity square bar | 30 mm |
| Capacity hexagon bar | 36 mm |
| Max. stroke of long slide | 125 mm |
| Machining rate: | |
| from | 1 s |
| up to | 280 s |
| Spindle speeds: | |
| number (steps) | 49 |
| from | 315 t/min |
| up to | 2240 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Power | 22 kW |
| Machine's weight about | 10000 kg |
| Overall dimensions machine: | |
| Length | 6500 mm |
| Width | 1400 mm |
| Height | 2100 mm |
| Various accessories: | |
| Bar feeder | |
| Chip conveyor |
