| Rotary table:diameter | 400 mm |
| Longitudinal travel (X-axis) | 400 mm |
| Cross travel (z-axis) | 350 mm |
| vertical travel (Y-axis) | 375 mm |
| Table load max. | 160 kg |
| Taper in spindle | 40 ISO |
| Spindle speeds: | |
| stepless | |
| horizontal from | 20 t/min |
| up to | 3150 t/min |
| vertical from | 20 t/min |
| up to | 3150 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Total power required | 9 kVA |
| Machine's weight about | 1600 kg |
| Overall dimensions machine: | |
| Length | 1600 mm |
| Width | 2200 mm |
| Height | 1670 mm |
