ELB SWH 5 NC-K is a Surface grinder delivering high precision, accuracy and reliable operation. Capacities: table 750×200 mm; grinding 500×250 mm; height 375 mm; max distance table–spindle centre 525 mm. Specs: table speed stepless ≤30 m/min; wheel Ø300×25 mm, 1400–2800 t/min; spindle motor 1.50 CV; 3x380 V 50 Hz; weight ≈2250 kg. Equipment: coolant system, magnetic plate 500×250 mm, redressing device, creep feed. Applications: automotive, aerospace, watchmaking, precision engineering.
Technical specifications are subject to change without notice
| Table length | 750 mm |
| Table width | 200 mm |
| Grinding length | 500 mm |
| Grinding width | 250 mm |
| Grinding height | 375 mm |
| Max. distance from table | |
| to spindle-centreline | 525 mm |
| Table speeds: | |
| stepless | |
| up to | 30 m/min |
| Diameter of grinding wheel | 300 mm |
| Width of the grinding wheel | 25 mm |
| Grinding wheel speeds: | |
| number (steps) | 2 |
| from | 1400 t/min |
| up to | 2800 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Grinding spindle motor | 1.50 CV |
| Machine's weight about | 2250 kg |
| Various accessories: | |
| Coolant system | |
| Magnetic plate: | |
| Length | 500 mm |
| Width | 250 mm |
| Redressing device | |
| Creep feed |
