| Centre height | 95 mm |
| Distance between centres | 250 mm |
| Table length | 450 mm |
| Table width | 175 mm |
| Max. grinding diameter | 130 mm |
| Transversal way of the table | 260 mm |
| Vertical adjustment of the table | 50 mm |
| Vertical adjustment of grinding head | 50 mm |
| Table swivels | 360 ° |
| Slewing range of grinding head: | |
| horizontal | 360 ° |
| vertical | 220 ° |
| Grinding spindle speeds: | |
| number (steps) | 2 |
| from | 3750 t/min |
| up to | 7500 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Total power required | 1 CV |
| Machine's weight about | 450 kg |
| Overall dimensions machine: | |
| Length | 1000 mm |
| Height | 1500 mm |
| Various accessories: | |
| Dust extraction | |
| Lamp | |
| Vice: width | mm |
DECKEL SVK (S1) is a Tool and cutter grinder engineered for precision, high accuracy and reliable performance. Working capacities: centre height 95 mm, distance between centres 250 mm, table 450×175 mm, max. grinding diameter 130 mm; table transversal travel 260 mm; vertical adjustments table/head 50 mm; table/head swivel 360°/220°. Main specs: grinding spindle 2 steps 3,750–7,500 rpm; voltage 50 Hz 3x380 V; total power 1 CV; machine weight approx. 450 kg; dimensions L 1000 × H 1500 mm. Accessories: dust extraction, lamp and vice (jaw width not specified). Delivers tight tolerances for automotive, watchmaking, machine tools, aerospace and medical applications.
Technical specifications are subject to change without notice
