LIZZINI NO 3 is a Tool and cutter grinder designed for precision, high accuracy and reliability. Capacities: centre height 130 mm, distance between centres 800 mm, table 1214×140 mm, max. grinding diameter 260 mm, max. wheel 200 mm, spindle taper 5 CM, workpiece speed 360 t/min, grinding spindle up to 4500 t/min. Specs: 50 Hz 3x 380 Volt, grinding spindle motor 2 CV, machine weight about 1100 kg, dimensions L2180×W1420×H1760 mm. Accessories: 2 tailstocks and set of centers. Enables tight tolerances; typical sectors: automotive, watchmaking, machine tools, aerospace, medical.
| Centre height | 130 mm |
| Distance between centres | 800 mm |
| Table length | 1214 mm |
| Table width | 140 mm |
| Max. grinding diameter | 260 mm |
| Max. grinding wheel diamter | 200 mm |
| Taper in spindle: | 5 CM |
| Work piece spindle speed | 360 t/min |
| Grinding spindle speeds: | |
| up to | 4500 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Grinding spindle motor | 2 CV |
| Machine's weight about | 1100 kg |
| Overall dimensions machine: | |
| Length | 2180 mm |
| Width | 1420 mm |
| Height | 1760 mm |
| Various accessories: | |
| Tailstocks | 2 x |
| Set of centers |
