Technical data
Table length
500 mm
Table width
220 mm
Grinding length
550 mm
Grinding width
225 mm
Grinding height
200 mm
Execution:
hydraulic
with automatic cycle
Max. distance from table
to spindle-centreline
325 mm
Longitudinal travel (X-axis)
500 mm
Cross travel (z-axis)
250 mm
Vertical travel (Y-axis)
300 mm
Automatic cross-feed:
from
0 m/min
up to
2.5 m/min
Table speeds:
from
0 m/min
up to
25 m/min
Automatic vertical feed:
from
0.005 mm
up to
0.05 mm
Vertical rapid traverse
0.23 m/min
Diameter of grinding wheel
250 mm
Width of the grinding wheel
25 mm
Wheel int. diameter
76.2 mm
Grinding wheel speeds:
up to
2100 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
3 kW
Machine's weight about
1400 kg
Overall dimensions machine:
Length
1850 mm
Width
1320 mm
Height
1700 mm
Various accessories:
Coolant system
Redressing device
Lamp
Technical specifications and pictures without guarantee.
