Technical data
Number of axis total
3
Table length
600 mm
Table width
400 mm
Number of T-channels
5
Distance of the T-slots
80 mm
T-channel width
14 mm
Table load max.
60 kg
Longitudinal travel (X-axis)
420 mm
Transversal travel (y-axis)
350 mm
Vertical travel (z axis)
200 mm
Dimension of the workpice:
Diameter
6 mm
Tool changer:
Number of tools
45
Spindle nose: HSK
E25
Distance spindle nose to table
115 - 315 mm
Spindle speeds:
stepless
from
6000 rpm
up to
40000 rpm
Feed range
0 - 4000 mm/min
Rapid traverse:
36 m/min
Voltage 50 Hz 3x
400 Volt
Machine's weight about
5800 kg
Overall dimensions machine:
Length
1625 mm
Width
1500 mm
Height
2105 mm
Technical specifications and pictures without guarantee.
