Technical data
Table length
800 mm
Table width
250 mm
Grinding length
800 mm
Grinding width
300 mm
Max. distance from table
to spindle-centreline
550 mm
Longitudinal travel (X-axis)
900 mm
Transversal travel (y axis)
310 mm
Automatic cross-feed:
stepless
up to
6 m/min
from
2 mm
up to
30 mm
Table speeds:
stepless
from
0 m/min
up to
30 m/min
Automatic vertical feed:
from
0.001 mm
up to
0.099 mm
Diameter of grinding wheel
350 mm
Width of the grinding wheel
40 mm
Wheel int. diameter
127 mm
Grinding wheel speeds:
from
1400 rpm
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
4 kW
Total power required
6.6 kW
Machine's weight about
1800 kg
Overall dimensions machine:
Length
3350 mm
Width
1870 mm
Height
1900 mm
Various accessories:
Paper filtration system
Grinding wheel with flange
Balancing arbor
Balancing support
Technical specifications and pictures without guarantee.
