Technical data
Table length
600 mm
Table width
250 mm
Axial motion:
Longitudinal travel (X-axis)
600 mm
Cross travel (z-axis)
280 mm
Max. distance from table
to spindle centreline
500 mm
Grinding length
600 mm
Table speeds:
stepless
from
1 m/min
up to
24 m/min
Creep feed:
from
0.03 m/min
up to
0.40 m/min
Automatic cross feed:
stepless
from
0.010 mm/min
up to
10000 mm/min
Voltage 50 Hz 3x
380 Volt
Grinding spindle motor
9.5 kW
Total power required
13 kVA
Machine's weight about
2500 kg
Overall dimensions machine:
Length
2910 mm
Width
2320 mm
Height
1840 mm
Various accessories:
Coolant system
High pression colant device
Paper filtration system
Electrical magnetic chuck
Length
500 mm
Width
200 mm
Diaform profiling device
Rapport 5:2
Handwheel electroinic
Automatic central lubrication
Technical specifications and pictures without guarantee.
