Technical data
Diameter of work admitted
4.00 mm
Max. turning length:
with flat cames
28 mm
Spindle hole
6.00 mm
Max. treading diameter
4 M (Metric)
Number of tool cutters
5
Spindle speeds:
Number of spindle speeds
14
from
2000 rpm
up to
12000 rpm
Voltage 50 Hz 3x
380 Volt
Total power required
1.5 HP
Machine's weight about
350 kg
Overall dimensions machine:
Length
1000 mm
Width
700 mm
Height
1300 mm
Various accessories:
3-spindle drilling attachment
Lamp
Protective cover
Rocker arm with 1/1000 mm
Technical specifications and pictures without guarantee.
