Technical data
Drill capacity in steel
13 mm
Table length
400 mm
Table width
280 mm
Depth of throat
200 mm
Spindle stroke
120 mm
Spindle speeds:
number (steps)
10
from
350 rpm
up to
5000 rpm
Distance from table to spindle nose:
min.
30 mm
max
330 mm
Voltage 50 Hz 3x
380 Volt
Power
1.00 HP
Machine's weight about
110 kg
Overall dimensions machine:
Length
800 mm
Width
550 mm
Height
600 mm
Various accessories:
Drill chuck
Lamp
Technical specifications and pictures without guarantee.
