Technical data
Diameter of work admitted
10 mm
Max. turning length:
with flat cames
70 mm
with bell cames
100 mm
Spindle hole
12.5 mm
Max. treading diameter
8 M (Metric)
Number of tool cutters
5
Spindle speeds:
Number of spindle speeds
20
from
1050 rpm
up to
8000 rpm
Voltage 50 Hz 3x
380 Volt
Total power required
3 HP
Machine's weight about
860 kg
Overall dimensions machine:
Length
1500 mm
Width
750 mm
Height
1450 mm
Various accessories:
3-spindle drilling attachment
Protective cover
Rocker arm with 1/1000 mm
Technical specifications and pictures without guarantee.
