Technical data
Work capacity:max. diameter
36 mm
Max. module
1.00
Workpiece length max.
80 mm
max. gear wheel width
50 mm
Pitch min.
6
max.
200
Milling stroke
10 mm
Gear hob:
max. diameter
32 mm
Milling cutter speeds:
number (steps)
8
from
660 rpm
up to
5300 rpm
Feeds:
stepless
up to
60.0 mm/r
Voltage 50 Hz 3x
380 Volt
Power
0.70 HP
Total power required
1.2 HP
Machine's weight about
680 kg
Overall dimensions machine:
Length
800 mm
Width
800 mm
Height
1400 mm
Various accessories:
Parts catcher
Lamp
Coolant system
Technical specifications and pictures without guarantee.
